High Quality Well Resistance Tungsten Carbide Punching Dies

FOB Reference Price:Get Latest Price
US $40-50 / Kilograms | 1 Kilogram/Kilograms (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Hunan, China (Mainland)
Brand Name:
lizhou
Model Number:
As Your Requirements
Alloy Specification:
YG6/YG8/YG8C/YG11/YG11C
Particle:
Coarse size 2.4μm---3.2μm or As Your Requirements
Materials:
100% Virgin Tungsten Carbide
Commodity Name:
Carbide Punching Dies
Application:
Punching Nut and Processing Tool
Certificate:
ISO9001
Type:
As Your Requirements
Hardness:
81-85
TRS:
2500-2800
Density:
13.1-13.8
Binding phase:
18-25
Supply Ability
Supply Ability:
300 Ton/Tons per Year
Packaging & Delivery
Packaging Details
Carbide Punching Dies Packed in Export Standard Package or As Your Requirements.
Port
Zhuzhou Shanghai Shenzhen Guangzhou or As Your Required
Lead Time :
Within 10 Days after Receipt of Your Payment in Advance

 High Quality Well Resistance Tungsten Carbide Punching Dies


Product Description




ZHUZHOU LIZHOU carbide cold heading die nibs and moulds have good impact resistance, fatigue resistance and wear resistance. You are encouraged to use our professional carbide grades for cold heading and punching die nibs, powder metallurgical compacting dies and other industries. For stable performance and high cost effectiveness, they have been proved to be ideal in making nonferrous metal, ferrous metals and their alloys.
Our cold heading dies (material dies) are good quality and high performance. Various sizes and styles are available to meet yours requirement.


Application: These Cold Dies are mainly used in processing some hard metal tools, especially for bolts, rivets, heading of screws and nuts, which is high impact resistance, toughness and wear resistance.



Recommended Grade

Grade

Binding phase(%)

Grain Size(um)

Density(g/cm3)

Hardness(HRA)

TRS(Mpa)

LC40

18

3.2

13.75

>=85

>=2500

LC5020

3.2

13.60

>=83.5

>=2800

LC6022

3.2

13.40

>=82.5

>=2600

LC7025

3.2

13.15

>=81.5

>=2500





(ID)Size and Tolerance:

IDH

≤2

≤18

>18~30

>30~45

>45~60

>2~4

-0.5/-0.1



-0.5/-0.1-0.1/-0.7-0.6/0

>4~6

-0.5/-0.1-0.5/-0.1-0.1/-0.7-0.6/0

>6~10

-0.6/+0.1-0.6/+0.1-0.1/-1.0-1.0/0

>10~18

-0.6/+0.1-0.6/+0.1-0.1/-1.0-1.5/0

>18~30

-0.1/+1.0-0.1/+1.0-0.1/-1.0-1.5/0



(H)Size and Tolerance:

H

≤10

>10~18

>18~30

>30~50

>50

(TOL.)

+0.1/+0.3+0.5/+1.0+0.2/+0.8+0.2/+1.0+0.3/+1.5



(OD)Size and Tolerance  :

IDH

≤2

≤18

>18~30

>30~45

>45~60

>2~4

+0.2/+1.0 +0.2/+1.0 +0.2/+1.0  +0.2/+1.0

>4~6

+0.2/+1.0-0.5/-0.1+0.2/+1.0+0.2/+1.0

>6~10

+0.2/+1.0-0.6/+0.1+0.2/+1.0+0.2/+1.0

>10~18

+0.2/+1.0-0.6/+0.1+0.2/+1.0+0.2/+1.0

>18~30

+0.2/+1.0-0.1/+1.0+0.2/+1.0+0.2/+1.0



We are accept the size as per the customers’ requirement.

ALSO, we warmly welcome you and your drawing papers
